Two Way Speaking COFDM Transmitter Military 10 Watt Wireless AV Sender Video & Data

Name: Two Way Speaking COFDM Transmitter Military 10 Watt Wireless AV Sender Video amp Data
Brand: Kimpok
Price: 1 USD

Buy cheap Two Way Speaking COFDM Transmitter Military 10 Watt Wireless AV Sender Video & Data product

Brand Name : Kimpok

Model Number : KP-C10

Certification : CE/FCC/ROHS

Place of Origin : China

MOQ : 1 set

Price : Negotiaiton

Payment Terms : T/T, Western Union,PayPal

Supply Ability : 2,000pcs per month

Delivery Time : 3-7 days

Packaging Details : export standard packing

Modulation : COFDM 2K QPSK

Frequency : 300-800MHz(option), 12G/2.4G/5.8GHz(customized)

RF Power Output : 10W

Voltage : DC11-14.5V

Current : 2.7A

Distance : 150 km LOS distance (on helicopter), 5-6km NLOS distance(in city)

Contact Now

Two Way Speaking COFDM Transmitter Military 10 Watt Wireless AV Sender Video & Data

ntroduction:

The device is our New Sole design COFDM transmitter and receiver KP-C10. Has a character of Walkie Talkie functio,long range remote control and more intuitive as well natural. Use H.264 coding format and COFDM (coded orthogonal frequency division multiplexing) modulation, provide high quality of picture in revolution 720*576, short latency. Support NLOS and high speed mobile transmission.Support parameters adjusted by user.PAL/NTSC video format self- adaption and good anti-intereference.This special designed system is for long range distance for military use, it is also popular to use in other fields for live broadcast video audio transmission.

Features:

10Watt rf power, strong penetration;
300-800MHz, 2.3-2.7GHz etc., adjustable frequency;
Video + data simultaneously.

Tech Specification:

Transmitter parameters:

Frequeny/AV	300-800MHz(adjustable),1.2G/2.4G/5.8GHz(customized) can be adjustable by user,100MHz interval.
Frequeny/DATA	200-270MHz(adjustable),or other band
Modulation	COFDM 2K QPSK
RF power output	10W
Voltage	DC11-14.5V
Current	2.7A
Video rate	15Mbps(MAX)
Constellation	QPSK,16QAM,64QAM(optional), QPSK/16QAM/64QAM @ 6/7/8MHz
FEC	1/2,2/3,3/4,5/6, 7/8 (optional)
Guard Interval	1/32,1/16,1/8,1/4 (optional)
Bandwidth	2/2.5/4/8M(adjustable)
A/V Interface	BNC / RCA
Encryption	AES 128 bit / ALLTECH Basic scrambling
Flatness	Full band≤2dB ,8MHz≤0.5dB
Carrier	2K,8K
SHG	>52dBc
Video Signal	1Vp-p@75Ω,NTSC/PAL adaptive
CBER	<2.0E-4
Video Compression	MPEG-2 4:2:0 /MPEG-4 (optional)
Resolution	720×576(PAL) , 720×480(NTSC)
Video/image	720x576 @ 8MHz, 352x288 @ 1.25MH
RS232/RS485 control interface	Standard RS232/RS485 level,9600,8,N,1
RS232/RS485 data interface	Standard RS232/RS485 level ,support 1200~115200
Video Input	1Vp-p@75Ω,NTSC/PAL (autoadaptation)
Audio Input	Analog stereo left and right channels
RF Interface	N(type)
AV Interface	BNC
Video decoding	ISO/IEC13818-2 MPEG-2MP@ML
OperatingTemperature	-25℃~55℃
Storage Temperature	-40℃~70℃
Distance	150 km LOS distance (on helicopter), 5-6km NLOS distance(in city)
Material Type of Case	Aluminum (black)
Size	20013060mm
Weight	2.8kg

Receiver parameters:

Frequeny/AV	300-800MHz(adjustable),1.2G/2.4G/5.8GHz(customized)
Frequeny/DATA	200-270MHz(adjustable)
Modulation	COFDM 2K QPSK
Receive sensitivity	-105dBm
Voltage	DC12-14V
Constellation	QPSK,16QAM,64QAM (optional)
RF Level Input	-92dBm~-20dBm / -105dBm~-20dBm
RF Impedance	50Ω
Carrier	2K,8K
FEC	1/2,2/3,3/4,5/6, 7/8 (optional)
Guard Interval	1/32,1/16,1/8,1/4 (optional)
Bandwidth	2/2.5/4/8M(adjustable)
Video Decoding	ISO/IEC13818-2 MPEG-2MP@ML
AV output	2 Audio output+2Video input
Audio output mode	Analog stereoStereo unbalanced 300/200 mV
Video resolution	720x576 @ 8MHz, 352x288 @ 1.25MHz
Video format	PAL / NTSC (autoadaptation)
Audio output	Analog stereo left and right channels
aspect ratio	4:3, 16:9
Encryption	AES 128 bit / ALLTECH Basic scrambling
Carrier	2K,8K
Video Compression	MPEG-2 4:2:0 /MPEG-4 (optional)
Resolution	720×576(PAL) , 720×480(NTSC)
RS232/RS485 control interface	Standard RS232/RS485 level,9600,8,N,1
RS232/RS485 data interface	Standard RS232/RS485 level ,support 1200~115200
RF Interface	N(type)
AV Interface	BNC
OperatingTemperature	-25℃~55℃
Storage Temperature	-40℃~70℃
Size	43031065mm(1U chassis)
Weight	3.8kg

Packaging Details
Accessories	2*antennas (customized); RF cables and mounted kits.
Style	Paper carton
Size	Undetermined

Two Way Speaking COFDM Transmitter Military 10 Watt Wireless AV Sender Video & Data

Poduct application:

Two Way Speaking COFDM Transmitter Military 10 Watt Wireless AV Sender Video & Data
